Lutron FCJS-010 0-10v PowPak Relay Module

Lutron FCJS-010 0-10v PowPak Relay Module

• The PowPak wireless fixture control is a radio-frequency (RF) device that controls either the Lutron EcoSystem or 0 –10 Velectronic fluorescent ballasts and LED drivers (depending on model). This is based on RF input from Pico remote controls, Radio Powr Savr wireless sensors, or wired inputs from the PowPak fixture sensor. The control module mounts to a fixture or a U.S.-style junction box. Communication with RF input devices is accomplished using Lutron Clear Connect RF Technology. See Applications and Selecting the Right Control for more details on selecting the appropriate controls for your application.

• The PowPak fixture sensor (optional) mounts to the ceiling or to a fixture and measures light in the space (daylighting) while detecting people moving within an area to determine passive infrared occupancy. The sensor controls the lights to balance light level in the space, combining convenience, exceptional energy savings, and ease of installation. The sensor contains two wires which connect to the PowPak wireless fixture control.

• These products are also compatible with the Vive hub which enables a simple setup process using a standard web browser on any Wi-Fi® enabled phone, tablet or computer. It also enables control and monitoring of all Vive devices. The Vive hub can be added at any time. System reprogramming will be required. For a complete list of features supported with the Vive hub, see specification submittal 369902 at www.lutron.com

Features
• Softswitch: Lutron patented technology prevents arcing of relay contacts, extending product lifetime
• Various operating voltages available—refer to model number chart on next page for details on voltage requirements
• Capable of switching general-purpose loads
• New model available for use with emergency lighting 1
• Optional low-voltage dry contact closure output provides integration to building management systems, HVAC, VAV, etc.
• Receives wireless inputs from up to 10 Pico remote controls, 10 Radio Powr Savr occupancy / vacancy sensors, and 1 Radio Powr Savr daylight sensor
• Utilizes Lutron Clear Connect RF Technology—refer to model number chart on next page for frequency band data
• Mounts to a U.S. style junction box through a standard size knockout
