American Lighting HTL20‑PXL‑RGBW6‑24VDC‑16 is a 24 V DC digital‑pixel RGBW tape light featuring SMD 5050 LEDs with 6‑LED pixel resolution, fully controllable via DMX‑512.
Features
• Seamless COB design: Creates a smooth, dot‑free linear lighting effect—ideal for low‑clearance or highly reflective installations
• High lumen output: Delivers ~434 lm/ft at 5000 K, with a CRI 90+ and 120° beam spread
• Efficient power usage: Uses 4.5 W/ft, typical of high‑output 24 V COB tape
• Operating voltage: 24 V DC with runs up to 16.4 ft per reel
• Temperature and lifespan: Rated for 50,000 hours, operates between 5 °C and 70 °C
• Cut increments: Field-cuttable every 1.96″ (~50 mm) for precise runs
• Slim form factor: Measures ~0.39″ (10 mm) wide and 0.09″ (2.3 mm) thick; weighs ~0.6 lb
• Easy mounting: Backed by 3M VHB adhesive, includes IP65-rated jacket and wet location approval with cULus listing
• Dimmable control: Compatible with TRIAC/ELV dimmers (5–100%)
• Industry standards: Title 24 / JA8 compliance; cULus listed for dry, damp, or wet locations
