American Lighting LED-DR600-24 600 Watt 24 Volt LED Driver Non-Dimmable
American Lighting 60W LED constant voltage driver is recommended to be used for powering secondary side dimming controls in low voltage LED fixture applications.
$786.78
Features
• 60W capacity, 24V DC.
• Non-dimmable on primary side, utilize secondary side for Trulux controls or PWM dimming.
• Universal AC input / full range.
• Protections for short circuit, overload, and over voltage.
• Built-in constant current limiting circuit.
• Fully isolated plastic case, fully encapsulated with IP67 level.
• Class 2, Class II (no FG)
• Set upon flat surface or house in an enclosure.
• 60W capacity, 24V DC.
• Non-dimmable on primary side, utilize secondary side for Trulux controls or PWM dimming.
• Universal AC input / full range.
• Protections for short circuit, overload, and over voltage.
• Built-in constant current limiting circuit.
• Fully isolated plastic case, fully encapsulated with IP67 level.
• Class 2, Class II (no FG)
• Set upon flat surface or house in an enclosure.
| Part Number | LED-DR600-24 |
|---|---|
| Manufacturer | American Lighting |
| Watts | 600 Watts |
| Input Voltage | 100V-277V |
| Output Voltage | 24V |
| Minimum Operating Temperature | -40C |
| Maximum Operating Temperature | 90C |
| Dimmable | No |
| Certifications |    |
| Lead Time | Ships in 2-3 Business Days |
