SIZE: 4” x 4” x 25” (8” vector)
HOUSING: Architectural-grade (6063-T6) 1/8” aluminum. 3/16”-thick aluminum base plate.
STANDARD POWDER COAT COLORS: PPG PCT23104 Vintage Brown Texture is standard for the D-Vine. Available in additional colors per the chart below. Other custom colors are also available.
SOCKET AND LAMP: 12V 7W 120° 3000K MR16 Dauer LED replaceable lamp (486720) included. ZINC ANODE: 3/8-16 NPT replacement zinc anode (502021) included.
MOUNTING OPTIONS: Deck Mounting and Concrete Mounting hardware included. Stake mount option can be ordered separately (489600).
OTHER OPTIONS: Four-sided design is standard, but can be ordered with black-out on 1, 2, or 3 sides. Any custom color is available. Custom designs and logos are available. Interior kit available.
WIRING: Pre-wired with 5’ 18/2 lead.
WARRANTY: Lifetime on fixture. Ten-year warranty on powder coating. Five-year warranty on the replaceable LED lamp.
| Part Number | 489550 |
|---|---|
| Manufacturer | Dauer |
| Input Voltage | 12V |
| Dimmable | No |
| Dimensions | 4" x 4" x 25" |
| Certifications | ![]() |
| Warranty | 10 Year |
| Lead Time | Build Item 8+ Weeks |
