Duraguard GNVP53Q 23w DuraLED LEDicated Vaporproof with Gooseneck Arm

Description: The DuraGuard LEDicated Vaporproof Gooseneck LED luminaire is available with 5 Gooseneck arms of various lengths and is designed to replace HID lighting systems up to 175w MH or HPS. This vapor resistant fixture can withstand extreme physical and environmental abuse and is ideal for retail centers, industrial parks, schools and universities, public transit and airports, office buildings and medical facilities. Designed for architectural wall mounting up to heights of 20 feet based on light level and uniformity requirements.

Specifications and Features:
Housing: Heavy Duty Die Cast Aluminum Housing with Integral Heat Sinking, 3/4" NPS Threaded Mount.
Listing & Ratings: CSA: Listed for Wet Locations, ANSI/UL 1598, 8750 IP66 Sealed LED Compartment.
Finish: Powdercoat Finish Over a Chromate Conversion Coating. Custom Colors Available Upon Request. Lens:
Flat Clear Tempered Glass Lens Mounting: Fixed Mount or Adjustable Swivel with 3/4” NPS Threads.
Wattage: Array: 23w, System: 27w; (175w HID Equivalent)
Driver: Electronic Driver, 120-277V, 50/60Hz; Less Than 20% THD and PF>0.90. Standard Internal Surge Protection 2kV. 0-10V Dimming Standard for a Dimming Range of 100% to 10%; Dimming Source Current is 150 Microamps.

Gooseneck Arm Specifications and Features:
Construction: Heavy-Duty 3/4" Aluminum Arms with 3/4" NPS Threads on Fixture Mounting End.
Finish: Powdercoat Finish Over a Chromate Conversion Coating. Custom Colors Available Upon Request.
Mounting Options: Mount with 3/4" Square or Round Mounting Plates.
