Halco FPLCR-14-LS-CS-UNV-EM 1x4 Flat Panel Wattage and CCT Selectable Controls Ready Emergency Battery Backup120-277 Volt Emergency Battery Backup 90527
The Flat Panel Series is a family of highly efficient, versatile, configurable recessed fixtures, designed for recessed applications.
Performance
•Field selectable CCT ( 3500K, 4000K, 5000K)
• Field selectable lumen output
• 120-277V, 50/60 Hz 0-10V dimming driver to 10%
• 80 CRI • L70 Lumen maintenance > 50,000 hours
• 5 year limited warranty
Construction
• Steel housing with aluminum frame
• Field selectable CCT switch
• Field selectable lumen output switch
• Optional extended junction box for additional wiring space
Certifications
• cETLus rated for damp locations
• IC Rated for direct contact with insulation
• DLC Premium listed
• Product can be used to comply with CA Title 24 standards
• IP20
• RoHS compliant
• FCC part 15 compliant
• TAA compliant
| Part Number | FPLCR-14-LS-CS-UNV-EM |
|---|---|
| Manufacturer | Halco Lighting |
| Troffer Size | 1' x 4' |
| Troffer Style | Flat with Lens |
| Color Temperature | 3000 Kelvin, 4000 Kelvin, 5000 Kelvin |
| Watts | 20 Watts, 25 Watts, 30 Watts |
| Lumens | Variable, See Spec Sheet |
| Lumens Per Watt | Variable, See Spec Sheet |
| CRI | 80 |
| Input Voltage | 120V-277V |
| Dimmable | Yes |
| Rated Life | 50,000 hours + |
| Minimum Operating Temperature | -4°F |
| Maximum Operating Temperature | 104°F |
| Dimensions | 47 3/4" x 11 5/16" x 1 5/8" |
| Certifications |    |
| Warranty | 5 Year |
| UPC Code | 807154905270 |
| Lead Time | In Stock - Quick Ship |
