Construction
• Rugged die-cast aluminum housing.
• Cast aluminum wiring access door located in lower hub/fitter.
• Rigid die-cast aluminum arms for consistency and strength.
• Precision die cast aluminum heatsink and optical frame.
• Removable spun aluminum cap/driver enclosure is retained by captive stainless steel fasteners and safety cables. Housing and top cap interface is sealed with a onepiece extruded silicone gasket. Tool-less entry option is available.
• All exposed fasteners are black oxide coated stainless steel. Internal fasteners are stainless steel or zinc electroplated steel.
• IP65 rated luminaire protects integral components from harsh environments.
• 1.5G rated for ANSI C136.31 high vibration applications
• Fixtures are finished with LSI’s DuraGrip® polyester powder coat finishing process. The DuraGrip finish withstands extreme weather changes without cracking or peeling. Other standard LSI finishes are available. Consult factory
| Part Number | ENM4 |
|---|---|
| Manufacturer | LSI |
| Lumens | Variable, See Spec Sheet |
| CRI | 70 |
| Color Temperature | 3000 Kelvin, 4000 Kelvin, 5000 Kelvin |
| Beam Angle | Variable |
| Dimmable | No |
| Input Voltage | 120V-277V, 347-480V |
| Rated Life | 100,000 hours + |
| Minimum Operating Temperature | -40°F |
| Maximum Operating Temperature | 122℉ |
| Dimensions | See Spec Sheet |
| Warranty | 5 Year |
| Lead Time | Build Item 3-4 Weeks |
